| 치 수 |
피치원외경 |
치선원외경 |
내 경 |
보수외경 |
보수길이 |
치 폭 |
전 폭 |
| Z |
P.C.D |
O.D |
A H7 |
B |
C |
D |
E |
| 12 |
24.0 |
28.0 |
10 |
18 |
10 |
20 |
30 |
| 13 |
26.0 |
30.0 |
10 |
20 |
10 |
20 |
30 |
| 14 |
28.0 |
32.0 |
12 |
20 |
10 |
20 |
30 |
| 15 |
30.0 |
34.0 |
12 |
24 |
10 |
20 |
30 |
| 16 |
32.0 |
36.0 |
12 |
26 |
10 |
20 |
30 |
| 17 |
34.0 |
38.0 |
12 |
28 |
10 |
20 |
30 |
| 18 |
36.0 |
40.0 |
12 |
30 |
10 |
20 |
30 |
| 19 |
38.0 |
42.0 |
12 |
31 |
10 |
20 |
30 |
| 20 |
40.0 |
44.0 |
12 |
32 |
10 |
20 |
30 |
| 21 |
42.0 |
46.0 |
12 |
34 |
10 |
20 |
30 |
| 22 |
44.0 |
48.0 |
12 |
36 |
10 |
20 |
30 |
| 23 |
46.0 |
50.0 |
12 |
37 |
10 |
20 |
30 |
| 24 |
48.0 |
52.0 |
12 |
38 |
10 |
20 |
30 |
| 25 |
50.0 |
54.0 |
12 |
40 |
10 |
20 |
30 |
| 26 |
52.0 |
56.0 |
12 |
42 |
10 |
20 |
30 |
| 27 |
54.0 |
58.0 |
12 |
45 |
10 |
20 |
30 |
| 28 |
56.0 |
60.0 |
12 |
45 |
10 |
20 |
30 |
| 29 |
58.0 |
62.0 |
12 |
47 |
10 |
20 |
30 |
| 30 |
60.0 |
64.0 |
12 |
50 |
10 |
20 |
30 |
| 32 |
64.0 |
68.0 |
12 |
50 |
10 |
20 |
30 |
| 34 |
68.0 |
72.0 |
12 |
50 |
10 |
20 |
30 |
| 35 |
70.0 |
74.0 |
12 |
52 |
10 |
20 |
30 |
| 36 |
72.0 |
76.0 |
12 |
55 |
10 |
20 |
30 |
| 38 |
76.0 |
80.0 |
12 |
55 |
10 |
20 |
30 |
| 40 |
80.0 |
84.0 |
15 |
55 |
10 |
20 |
30 |
| 42 |
84.0 |
88.0 |
15 |
55 |
10 |
20 |
30 |
| 44 |
88.0 |
92.0 |
15 |
55 |
10 |
20 |
30 |
| 45 |
90.0 |
94.0 |
15 |
55 |
10 |
20 |
30 |
| 46 |
92.0 |
96.0 |
15 |
55 |
10 |
20 |
30 |
| 48 |
96.0 |
100.0 |
15 |
55 |
10 |
20 |
30 |
| 50 |
100.0 |
104.0 |
15 |
55 |
10 |
20 |
30 |
| 52 |
104.0 |
108.0 |
15 |
55 |
10 |
20 |
30 |
| 54 |
108.0 |
112.0 |
15 |
55 |
10 |
20 |
30 |
| 55 |
110.0 |
114.0 |
15 |
55 |
10 |
20 |
30 |
| 56 |
112.0 |
116.0 |
15 |
55 |
10 |
20 |
30 |
| 58 |
116.0 |
120.0 |
15 |
60 |
10 |
20 |
30 |
| 60 |
120.0 |
124.0 |
15 |
60 |
10 |
20 |
30 |
| 62 |
124.0 |
128.0 |
15 |
60 |
10 |
20 |
30 |
| 64 |
128.0 |
132.0 |
15 |
60 |
10 |
20 |
30 |
| 65 |
130.0 |
134.0 |
15 |
60 |
10 |
20 |
30 |
| 66 |
132.0 |
136.0 |
15 |
60 |
10 |
20 |
30 |
| 68 |
136.0 |
140.0 |
15 |
60 |
10 |
20 |
30 |
| 70 |
140.0 |
144.0 |
15 |
60 |
10 |
20 |
30 |
| 72 |
144.0 |
148.0 |
15 |
60 |
10 |
20 |
30 |
| 75 |
150.0 |
154.0 |
20 |
60 |
10 |
20 |
30 |
| 76 |
152.0 |
156.0 |
20 |
60 |
10 |
20 |
30 |
| 80 |
160.0 |
164.0 |
20 |
60 |
10 |
20 |
30 |
| 84 |
168.0 |
172.0 |
20 |
70 |
10 |
20 |
30 |
| 85 |
170.0 |
174.0 |
20 |
70 |
10 |
20 |
30 |
| 88 |
176.0 |
180.0 |
20 |
70 |
10 |
20 |
30 |
| 90 |
180.0 |
184.0 |
20 |
70 |
10 |
20 |
30 |
| 95 |
190.0 |
194.0 |
20 |
70 |
10 |
20 |
30 |
| 100 |
200.0 |
204.0 |
20 |
70 |
10 |
20 |
30 |
| 120 |
240.0 |
244.0 |
20 |
90 |
10 |
20 |
30 |
|
