| 치 수 |
피치원외경 |
치선원외경 |
내 경 |
보수외경 |
보수길이 |
치 폭 |
전 폭 |
| Z |
P.C.D |
O.D |
A H7 |
B |
C |
D |
E |
| 15 |
15.0 |
17.0 |
8 |
17 |
20 |
10 |
30 |
| 16 |
16.0 |
18.0 |
8 |
18 |
20 |
10 |
30 |
| 17 |
17.0 |
19.0 |
8 |
19 |
20 |
10 |
30 |
| 18 |
18.0 |
20.0 |
8 |
20 |
20 |
10 |
30 |
| 19 |
19.0 |
21.0 |
8 |
21 |
20 |
10 |
30 |
| 20 |
20.0 |
22.0 |
8 |
16 |
10 |
10 |
20 |
| 21 |
21.0 |
23.0 |
8 |
17 |
10 |
10 |
20 |
| 22 |
22.0 |
24.0 |
8 |
18 |
10 |
10 |
20 |
| 23 |
23.0 |
25.0 |
8 |
18 |
10 |
10 |
20 |
| 24 |
24.0 |
26.0 |
8 |
20 |
10 |
10 |
20 |
| 25 |
25.0 |
27.0 |
8 |
20 |
10 |
10 |
20 |
| 26 |
26.0 |
28.0 |
8 |
22 |
10 |
10 |
20 |
| 27 |
27.0 |
29.0 |
8 |
22 |
10 |
10 |
20 |
| 28 |
28.0 |
30.0 |
8 |
22 |
10 |
10 |
20 |
| 29 |
29.0 |
31.0 |
8 |
24 |
10 |
10 |
20 |
| 30 |
30.0 |
32.0 |
10 |
25 |
10 |
10 |
20 |
| 32 |
32.0 |
34.0 |
10 |
26 |
10 |
10 |
20 |
| 34 |
34.0 |
36.0 |
10 |
26 |
10 |
10 |
20 |
| 35 |
35.0 |
37.0 |
10 |
26 |
10 |
10 |
20 |
| 36 |
36.0 |
38.0 |
10 |
28 |
10 |
10 |
20 |
| 38 |
38.0 |
40.0 |
10 |
32 |
10 |
10 |
20 |
| 40 |
40.0 |
42.0 |
10 |
35 |
10 |
10 |
20 |
| 42 |
42.0 |
44.0 |
10 |
35 |
10 |
10 |
20 |
| 44 |
44.0 |
46.0 |
10 |
35 |
10 |
10 |
20 |
| 45 |
45.0 |
47.0 |
10 |
35 |
10 |
10 |
20 |
| 46 |
46.0 |
48.0 |
10 |
35 |
10 |
10 |
20 |
| 48 |
48.0 |
50.0 |
10 |
35 |
10 |
10 |
20 |
| 50 |
50.0 |
52.0 |
10 |
35 |
10 |
10 |
20 |
| 52 |
52.0 |
54.0 |
10 |
35 |
10 |
10 |
20 |
| 54 |
54.0 |
56.0 |
10 |
35 |
10 |
10 |
20 |
| 55 |
55.0 |
57.0 |
10 |
35 |
10 |
10 |
20 |
| 56 |
56.0 |
58.0 |
10 |
35 |
10 |
10 |
20 |
| 58 |
58.0 |
60.0 |
10 |
35 |
10 |
10 |
20 |
| 60 |
60.0 |
62.0 |
10 |
35 |
10 |
10 |
20 |
| 62 |
62.0 |
64.0 |
10 |
40 |
10 |
10 |
20 |
| 64 |
64.0 |
66.0 |
10 |
40 |
10 |
10 |
20 |
| 65 |
65.0 |
67.0 |
10 |
40 |
10 |
10 |
20 |
| 66 |
66.0 |
68.0 |
10 |
40 |
10 |
10 |
20 |
| 68 |
68.0 |
70.0 |
10 |
40 |
10 |
10 |
20 |
| 70 |
70.0 |
72.0 |
10 |
40 |
10 |
10 |
20 |
| 72 |
72.0 |
74.0 |
10 |
40 |
10 |
10 |
20 |
| 75 |
75.0 |
77.0 |
10 |
40 |
10 |
10 |
20 |
| 76 |
76.0 |
78.0 |
10 |
40 |
10 |
10 |
20 |
| 80 |
80.0 |
82.0 |
10 |
40 |
10 |
10 |
20 |
| 84 |
84.0 |
86.0 |
10 |
40 |
10 |
10 |
20 |
| 85 |
85.0 |
87.0 |
10 |
40 |
10 |
10 |
20 |
| 88 |
88.0 |
90.0 |
10 |
40 |
10 |
10 |
20 |
| 90 |
90.0 |
92.0 |
10 |
40 |
10 |
10 |
20 |
| 95 |
95.0 |
97.0 |
10 |
40 |
10 |
10 |
20 |
| 96 |
96.0 |
98.0 |
10 |
40 |
10 |
10 |
20 |
| 100 |
100.0 |
102.0 |
10 |
40 |
10 |
10 |
20 |
| 110 |
110.0 |
112.0 |
15 |
50 |
10 |
10 |
20 |
| 120 |
120.0 |
122.0 |
15 |
50 |
10 |
10 |
20 |
|
