| 치 수 |
피치원외경 |
치선원외경 |
내 경 |
보수외경 |
보수길이 |
치 폭 |
전 폭 |
| Z |
P.C.D |
O.D |
A H7 |
B |
C |
D |
E |
| 12 |
18.0 |
21.0 |
8 |
21 |
15 |
15 |
30 |
| 13 |
19.5 |
22.5 |
8 |
22.5 |
15 |
15 |
30 |
| 14 |
21.0 |
24.0 |
8 |
16 |
10 |
15 |
25 |
| 15 |
22.5 |
25.5 |
8 |
19 |
10 |
15 |
25 |
| 16 |
24.0 |
27.0 |
8 |
20 |
10 |
15 |
25 |
| 17 |
25.5 |
28.5 |
8 |
21 |
10 |
15 |
25 |
| 18 |
27.0 |
30.0 |
8 |
22 |
10 |
15 |
25 |
| 19 |
28.5 |
31.5 |
8 |
23 |
10 |
15 |
25 |
| 20 |
30.0 |
33.0 |
8 |
24 |
10 |
15 |
25 |
| 21 |
31.5 |
34.5 |
8 |
25 |
10 |
15 |
25 |
| 22 |
33.0 |
36.0 |
8 |
26 |
10 |
15 |
25 |
| 23 |
34.5 |
37.5 |
8 |
27 |
10 |
15 |
25 |
| 24 |
36.0 |
39.0 |
8 |
28 |
10 |
15 |
25 |
| 25 |
37.0 |
40.5 |
8 |
30 |
10 |
15 |
25 |
| 26 |
39.0 |
42.0 |
10 |
32 |
10 |
15 |
25 |
| 27 |
40.5 |
43.5 |
10 |
34 |
10 |
15 |
25 |
| 28 |
42.5 |
45.0 |
10 |
36 |
10 |
15 |
25 |
| 29 |
43.5 |
46.5 |
10 |
37 |
10 |
15 |
25 |
| 30 |
45.0 |
48.0 |
10 |
38 |
10 |
15 |
25 |
| 32 |
48.0 |
51.0 |
10 |
40 |
10 |
15 |
25 |
| 34 |
51.0 |
54.0 |
10 |
40 |
10 |
15 |
25 |
| 35 |
52.0 |
55.5 |
10 |
42 |
10 |
15 |
25 |
| 36 |
54.0 |
57.0 |
10 |
45 |
10 |
15 |
25 |
| 38 |
57.0 |
60.0 |
12 |
45 |
10 |
15 |
25 |
| 40 |
60.0 |
63.0 |
12 |
45 |
10 |
15 |
25 |
| 42 |
63.0 |
66.0 |
12 |
45 |
10 |
15 |
25 |
| 44 |
66.0 |
69.0 |
12 |
45 |
10 |
15 |
25 |
| 45 |
67.5 |
70.5 |
12 |
45 |
10 |
15 |
25 |
| 46 |
69.0 |
72.0 |
12 |
45 |
10 |
15 |
25 |
| 48 |
72.0 |
75.0 |
12 |
45 |
10 |
15 |
25 |
| 50 |
75.0 |
78.0 |
12 |
45 |
10 |
15 |
25 |
| 52 |
78.0 |
81.0 |
15 |
50 |
10 |
15 |
25 |
| 54 |
81.0 |
84.0 |
15 |
50 |
10 |
15 |
25 |
| 55 |
82.5 |
85.5 |
15 |
50 |
10 |
15 |
25 |
| 56 |
84.0 |
87.0 |
15 |
50 |
10 |
15 |
25 |
| 58 |
87.0 |
90.0 |
15 |
50 |
10 |
15 |
25 |
| 60 |
90.0 |
93.0 |
15 |
50 |
10 |
15 |
25 |
| 62 |
93.0 |
96.0 |
15 |
55 |
10 |
15 |
25 |
| 64 |
96.0 |
99.0 |
15 |
55 |
10 |
15 |
25 |
| 65 |
97.5 |
100.5 |
15 |
55 |
10 |
15 |
25 |
| 66 |
99.0 |
102.0 |
15 |
55 |
10 |
15 |
25 |
| 68 |
102.0 |
105.0 |
15 |
55 |
10 |
15 |
25 |
| 70 |
105.0 |
108.0 |
15 |
55 |
10 |
15 |
25 |
| 72 |
108.0 |
111.0 |
15 |
55 |
10 |
15 |
25 |
| 75 |
112.5 |
115.5 |
15 |
60 |
10 |
15 |
25 |
| 76 |
114.0 |
117.0 |
15 |
60 |
10 |
15 |
25 |
| 80 |
120.0 |
123.0 |
15 |
60 |
10 |
15 |
25 |
| 84 |
126.0 |
129.0 |
15 |
60 |
10 |
15 |
25 |
| 85 |
127.0 |
130.0 |
15 |
60 |
10 |
15 |
25 |
| 88 |
132.0 |
135.0 |
15 |
60 |
10 |
15 |
25 |
| 90 |
135.0 |
138.0 |
15 |
60 |
10 |
15 |
25 |
| 95 |
142.5 |
145.5 |
15 |
60 |
10 |
15 |
25 |
| 100 |
150.0 |
153.0 |
15 |
60 |
10 |
15 |
25 |
| 120 |
180.0 |
183.0 |
15 |
70 |
10 |
15 |
25 |
|
